C3D 4 Axis Firmware & Config



Here is a step by step how-to for preparing the Cohesion3D Mini microSD card with the correct firmware and configuration for 4 axis use. This is needed if you wish to run a rotary or rotary and z axis.



Step 1. Power down the laser and remove the microSD card from the C3D controller

Step 2. Open the microSD card on your computer via microSD card reader/adapter

Step 3. Format the microSD card in the FAT file format

Step 4. Download the zxya firmware from here:  C3D 4 Axis Firmware (189 downloads)

Step 5. Download the 4 axis config file from here:  C3D 4 Axis Config File (156 downloads)

Step 6. Copy both files onto the microSD card in the root directory (no folders)

Step 7. Eject the microSD card from your computer and re-insert it into the C3D controller

Step 8. Power up the unit and test. You can use THIS ARTICLE to test it.

The official installation guide can be found here:

 https://cohesion3d.freshdesk.com/support/solutions/articles/5000744633-wiring-a-z-table-and-rotary-step-by-step-instructions
